Durable Thermal henkel gap pad for Electronics and Heat Management



Products Description

Main-01
Main-02



Henkel gap pad can effectively enhance thermal conductivity and help electronic devices dissipate heat better. It can quickly conduct the heat from the heat-generating components to the heat dissipation devices, keeping the components working at an appropriate temperature and enhancing performance and stability. Soft and highly comfortable materials can tightly fill the gap between the heating element and the heat sink, eliminate air gaps, significantly reduce thermal resistance, and make heat conduction smoother.



Our high thermal conductivity silicone pads have the following advantages:

1.Thermal Insulation

2.Soft shock absorption

3.Good plasticity

4.Easy to use

5.Wide range of applications



Typical properties



Color

Customized

Thickness, ASTM D374, mm

0.5~5.0

Hardness, ASTM D2240, Shore 00

55±5

Specific Gravity, ASTM D792

3.4±0.2

Thermal Conductivity, ASTM D5470, W/m.k

≥5.0

Tensile Strength, ASTM D412, psi

8

Dielectric Constant, ASTM D150, 1MHz

5.5

Flammability, UL 94

V-0

Operating Temperature, ℃

-50~180

ROHS

PASS

SVHC

PASS



Packing & Delivery

product-1089-106

.jpg






application



Henkel thermal pads are usually in sheet or die-cut shapes and come with peelable protective films, making them easy to operate. Workers only need to peel off the protective film and place it accurately at the position that needs to be filled. It offers a variety of standard sizes and thicknesses, and can also be customized according to special application requirements, such as custom die-cut parts with specific thicknesses and structures, to meet the unique design requirements of different equipment.And they are widely applied in the following scenarios;






Why Choose Us?



1. Our factory was established in 2004 has multiple empolyees, more than 18+years experience.
2. Fast delivery in cooperation with several logistics companies.
3. Carefully polish every detail to enhance the quality of the product.
4. Strictly select raw materials for better product quality.
5. Provide affordable and high quality products.








.jpg
